| Model | BPGP-300 | BPGP-400 | BPGP-600 | ||
| Quantity of Spindles | pcs | 1 | 1 | 1 | |
| Belt Width | mm | 320 | 420 | 620 | |
| Blade Diameter | mm | Φ300~Φ400 | Φ300~Φ400 | Φ300~Φ400 | |
| Max. Processing Width | mm | 300 | 400 | 600 | |
| Max. Processing Thickness | mm | 130 | 130 | 130 | |
| Range Of Cutting Speed | m/min | 20~300 | 20~300 | 20~300 | |
| Belt Speed | kw | 1~6 | 1~6 | 1~6 | |
| Spindle Motor Power | kW | 22 | 22 | 22 | |
| Belt Motor Power | kW | 1.5 | 1.5 | 1.5 | |
| Lifting Motor Power | kW | 0.55 | 0.55 | 0.55 | |
| Total Power | mm | 24.05 | 24.05 | 24.05 | |
| Overall Dimensions(L*W*H) | kg | 2100×1200×1700 | 2100×1400×1800 | 2100×1600×1800 | |
| Weight | kg | 1000 | 1050 | 1350 | |
